AM4113ZT

Product Description

The Dino-Lite Premier AM4113ZT is a 1.3 Megapixels handheld digital microscope with adjustable polarization. It is especially useful in suppressing glare from reflective materials, such as metals, plastics, or glass, and applicable in dermatology for observing the subdermal layer of skin. The convenient Dino-Lite design allows microscopy that can be brought to the field and examine large or small objects. This model is featured with variable optical magnification capable of up to 200x. With high sensitivity 1.3 Megapixels sensor to reveal more detail under polarization and high magnification.

Enhanced 1.3 Megapixels It observes with accurate color reproductions and retain details under low lighting with the optimum resolution for detailed live preview and captured images.

Up to 200x magnification Have the freedom to magnify from 20x to 50x the closer the Dino-Lite is to the target, using the Dino-Lite knob to focus for each magnification. Achieve an additional 200x when the Dino-Lite is at close range.

USB 2.0 Interface Digitize the microscopy experience; allow easy recording and sharing of observations in the office or out in the field with a compatible PC or MAC.

Professional measurement tools Use professional measurement tools that are calibratable for assured accuracy and convienently document or share information with the bundled software.

Adjustable polarization Useful for suppressing glare from reflective materials, such as metals, plastics, or glass, and applicable in dermatology for observing the sub dermal layer of skin.

Information about working distance and field of view M WD FOV (x) FOV (y) 20 48.7 19.6 15.6 30 21.7 13.0 10.4 40 9.0 9.8 7.8 50 1.9 7.8 6.3 60 -2.3 6.5 5.2 220 -0.1 1.8 1.4 230 1.0 1.7 1.4 240 2.1 1.6 1.3 M = magnification rate      WD = working distance (without front cap)      FOV = field of view      DOF= depth of field      Unit = mm
